PCI-6216V-GL

Karta 3.3/5 V PCI - 16 napięciowych wyjść analogowych 16-bitowych 454 kS/sek oraz 4 wejścia i 4 wyjścia cyfrowe

Zobacz wszystkie nasze karty akwizycji danych!

Features

• Supports a 32-bit 3.3 V or 5 V PCI bus
• 16-bit D/A resolution
• 16-CH voltage outputs
• Bipolar analog output range
• 4-CH TTL digital inputs and 4-CH TTL digital outputs

Specifications

• Voltage Output

• Number of channels: 16 voltage outputs
• Resolution: 16 bits
• Monotonicity: 15 bits typical
• Output ranges: ±10 V
• Slew rate:10 V/μs typical
• Settling time: 130 μs typical (20 V step)
• Gain Error: ±0.2% maximum
• DNL: ±0.65 LSB typical
• Output driving capacity: ±5 mA maximum
• Output initial status: 0 V
• Data transfer: programmed I/O

• Digital I/O

• Number of channels: 4 inputs and 4 outputs
• Compatibility: 5 V/TTL
• Data transfers: programmed I/O

• General

• I/O connector: One 37-pin D-sub female
• Operating temperature: 0˚C to 50˚C
• Storage temperature: -20˚C to 80˚C
• Relative humidity: 5% to 95%, non-condensing
• Power requirements: +5 V 1.2 A typical, +12V 280 mA typical
• Dimensions (not including connectors): 175 mm x 107 mm

Software Support

• Operating Systems

• Windows 7/Vista/XP/2000/2003 Server
• Linux
• Windows CE (call for availability)

• Recommended Software

• AD-Logger
• VB.NET/VC.NET/VB/VC++/BCB/Delphi
• DAQBench

• Driver Support

• DAQPilot for Windows
• DAQ-LVIEW PnP for LabVIEW
• DAQ-MTLB for MATLAB
• PCIS-DASK for Windows
• PCIS-DASK/X for Linux

Ordering Information

• PCI-6216V-GL - 16-CH 16-Bit Voltage Output Card

Accessories

• Terminal Boards

• DIN-37D-01 - Terminal Board with One 37-pin D-sub Connector and DIN-Rail Mounting

• ACLD-9137-01 - General-Purpose Terminal Board with One 37-pin D-sub Male Connector

• ACLD-9137F-01 - General-Purpose Terminal Board with One 37-pin D-sub female Connector.

• Cables

• ACL-10137-1MM - 37-Pin D-Sub M/M cable, 1M (DIN-37D-01, ACLD-9137F-01)

• ACL-10137-1MF - 37-Pin D-Sub M/F cable, 1M (ACLD-9137-01)
