Name: PCI-9223
Brand: Adlink Technology

Karta katalogowa Pobierz

Karta 3.3/5 V PCI - 16/32 wejść analogowych 16-bitowych 500 kS/sek, 2 wyjścia analogowe 16-bitowe 1 MS/sek, 16 wejść i 16 wyjść cyfrowych, 4 liczniki 32-bitowe i 2 wejścia enkodera

Zobacz wszystkie nasze karty akwizycji danych!

Features

Supports a 32-bit 3.3 V or 5 V PCI bus
Programmable gains for analog input: 1, 2, 4, 5, 8, 10, 20, 40
2-CH 16-bit simultaneous analog outputs, up to 1 MS/s analog output update rate
Programmable function I/O, supporting modes:
- TTL DI and TTL DO
- 2 MHz High-Speed DIO
- General-purpose timer/counter
- PWM outputs
- Encoder inputs
Dedicated 2-CH 4 MHz encoder inputs, supporting AB phase, and CW/CCW)
Dedicated DMA channels for A/D, D/A, and high-speed DIO
External digital trigger for A/D, D/A, and high-speed DIO
Multiple card synchronization through SSI (System Synchronization Interface) bus
Auto-calibration

Specifications

Analog Input

Resolution: 16 bits
Number of channels: 32 SE/ 16 DIFF
Maximum sampling rate (single channel): 500 kS/s
Programmable gain: 1, 2, 4, 5, 8, 10, 20, 40
Input range: ±10 V, ±5 V, ±2.5 V, ±2 V, ±1.25 V, ±1 V, ±500 mV, ±250 mV
Offset error: ±2.6 mV typical, before calibration, ±0.5 mV typical, after calibration
Gain error: ±0.2% of FSR, before calibration, ±0.015% of FSR, after calibration
-3 dB small signal bandwidth (gain=1): 1.5 MHz
System noise (gain=1): 0.5 mVRMS
CMRR (gain=1): 93.5 dB
SFDR: (Spurious-free dynamic range, gain=1): 88 dB
SINAD (Signal-to-noise and distortion ratio, gain=1): 84 dB
THD (Total harmonic distortion, gain=1): -90 dB
SNR (Signal-to-noise ratio, gain=1): 86 dB
ENOB (gain=1): 13.5 bits
FIFO buffer size: 1 k samples
Trigger sources: Software, external digital, SSI
Trigger mode: Post trigger, retrigger, gate trigger
External conversion source: Yes (up to 500 kS/s)
Input coupling: DC
Overvoltage protection: Continuous ±30 V
Input impedance: High impedance > 1 G
Data Transfer: Programmed I/O, Interrupt, Bus Mastering DMA

Analog Output

Number of channels: 2 voltage outputs
Resolution: 16-bit
Maximum update rate: 1 MHz (simultaneous update)
FIFO: 512
Output range: ±10 V
Output driving capacity: ±5 mA
Slew rate: 20 V/ s
Setting time (0.1% of full scale): 2.6 u s
Offset error: ±0.1 mV
Gain error: ±0.1 mV
Rising time: 0.67 us
Falling time: 0.705 us

Function I/O

Mode: Digital I/O, General Timer/Counter, Pulse Generation
Digital I/O: 16 DI (3.3 V or 5 V TTL Level) / 16 DO (3.3 V TTL Level)
General Timer/Counter: Four 32-bit, Base clock: 80 MHz, external to 10 MHz
Pulse generation:
Four PWM outputs (Modulation frequency: 0.01 Hz to 5 MHz; Duty cycle: 1%-99%)

Encoder Input

Number of channels: 2 dedicated
Encoder type:
CW/CCW encoder, x 1 AB phase encoder, x 2 AB phase encoder, x 4 AB phase encoder

General

PCI Bus: 5 V and 3.3 V universal PCI bus
Auto-calibration: Yes
I/O Connector: Two 68-pin SCSI-VHDCI female
Operation temperature: 0 ~ +55°C
Storage temperature: -20 ~ +70°C
Humidity: 5 to 95% non-condensing
Power requirements: +5 V 1.2 A typical, +12 V 760 mA typical, -12 V 50 mA typical
Dimensions: 175 mm x 107 mm (not including connectors)
