Name: GPSU06E-6
Brand: ICP DAS

Parametry techniczne:

Product Range:	Power Supply
Safety
Safety: Standard:	Meets or exceeds UL1950,CSA C22.2, TUV EN60950, IEC950.
EMC
EMC: Standard:	Meets conduction limits of FCC Part 15 Class B, CISPR 22.2
Input
Input: Voltage Range:	100-240 VAC
Input: Frequency Range:	50/60 Hz
Input: Inrush Current (Typ.):	COLD START 15 A @ 115 VAC, or 30 A @ 230 VAC at 25°C , 50MOhm min from output to ground (max.)
Input: Leakage Current:	0.25 mA/240 VAC (max.)
Output
Output: Ripple & Noise (Max.):	1% p-p max.
Output: Line Regulation:	1% max for input voltage change between input voltage range
Output: Load Regulation:	5% variations from min to max output current.
Output: Setup, Rise Time:	1000ms, 50ms, 12ms at full load
Output: Hold Up Time (Typ.):	5msec min.
Output: DC Voltage:	24 VDC
Output: Rated Power:	6 W
Output: Rated Current:	0.25 A
Output: Efficiency:	65% min at full output.
Protection
Protection: Over Voltage:	Yes (clamp by Zener diode)
Protection: Overload:	>110% rated output power , Protection type : Hiccup mode, recovers automatically after fault condition is removed
Mechaniczny
Mechanical: Casing:	Plastic
Mechanical: Dimensions (mm):	(62.5 * 32 * 66)mm
Środowisko
Environment: Temperature Coefficient:	All outputs 0.04%/°C max.
Environment: Operating Temperature:	0°C ~ +40°C
Environment: Storage Temperature:	-20°C ~ +85°C
Environment: Humidity:	20~ 90% RH, Non-condensing
Status:	Available
