Parametry techniczne:
| Product Range: | Power Supply |
Safety | |
| Safety: Standard: | UL62368-1, CSA C22.2 No.62368-1, TUV EN62368-1, BSMI CNS 14336-1 ,CCC GB4943.1, PSEJ62368-1,AS/NZS 60950.1, ,
BIS 1513252, KC K60950·1,EAC TP TC 004 approved |
EMC | |
| EMC: Standard: | EN55032(CISPR32),FCC PART 15 / CISPR22 ,
CAN ICES-3(B)/NMB-3(B), CNS13438 |
Input | |
| Input: Voltage Range: | 85-264VAC |
| Input: Frequency Range: | 47-63Hz |
| Input: AC Current (Typ.): | 0.6A/115VAC, 0.35A/230VAC |
| Input: Inrush Current (Typ.): | Cold start 35A/115VAC, 65A/230VAC |
| Input: Leakage Current: | 0.75 mA/240 VAC |
Output | |
| Output: Ripple & Noise (Max.): | 150mVp-p |
| Output: Setup, Rise Time: | 1000ms, 30ms |
| Output: Hold Up Time (Typ.): | 50ms/230VAC |
| Output: DC Voltage: | 24VDC |
| Output: Rated Power: | 25W |
| Output: Rated Current: | 1.04A |
| Output: Efficiency: | 88% typical |
Protection | |
| Protection: Over Voltage: | Yes (clamp by Zener diode). |
Mechaniczny | |
| Mechanical: Casing: | Plastic |
| Mechanical: Dimensions (mm): | (54 * 93 * 36)mm |
| Mechanical: Installation: | Desktop Style |
Środowisko | |
| Environment: Temperature Coefficient: | ±0.03%/°C (0~50°C) |
| Environment: Operating Temperature: | -30 °C~ +70°C |
| Environment: Storage Temperature: | -40 °C~ +85°C |
| Environment: Humidity: | 20% ~ 90% RH, Non-condensing |
| Status: | Available |
Jeśli potrzebujesz dodatkowych informacji zadzwoń do nas (22 831 10 42) lub napisz wiadomość.
