EPS-3032

Moduł EtherCAT Slave - 32 wejścia analogowe 16-bitowe ±10 V

Features

• 32-CH 100 kS/s ±10 V Single-ended type analog input
• Quick removable European type connector
• Slave module healthy monitoring
• Wide operation temperature range: -20 ~+60°C
• Compact size: 100 x 100 mm
• IEC-61131 compliant

Specifications

• Power Consumption: 2.5 W
• Hot Swap: Yes
• Operating Temp.: -20 ~ +60°C
• Analog Input Channel: 32
• Input Type: Single-ended
• Input Range: ±10 V
• Offset Error: ± 0.1 mV
• Gain Error: ± 0.05% of FSR
• Sampling rate: 100 KHz
• Resolution: 16 bit
• Connector Type: Phoenix Contact DFMC

Ordering Information

• EPS-3032 - EtherCAT Slave Module - 32-CH ±10 V Analog Input
