EPS-7002

Moduł EtherCAT Slave - 2 kanały sterowania silnikami krokowymi

Features

• 2-CH pulse-train motion control
• Quick removable European type connector
• Slave module healthy monitoring
• Wide operation temperature range: -20 ~ +60°C
• Compact size: 100 x 100 mm
• IEC-61131 compliant

Specifications

• Power Consumption: 2.5 W
• Hot Swap: Yes
• Operating Temp.: -20 ~ +60°C
• Pulse Output Channel: 2
• Pulse Output Frequency: 4 MHz
• Pulse Output Modes: CW/CCW, OUT/DIR
• Encoder Input Channel: 2
• Encoder Input Type: TTL, Incremental
• Encoder Input Frequency: 20 MHz (@ 4xAB mode)
• Encoder Input Modes: A/B phase, CW/CCW
• Motion I/O interface: PEL, MEL, ORG
• Servo I/O interface: ALM, INP, RDY, SVON, ERC, RST
• Input Type: Sinking
• Input Current: IEC-61131-2 Type 1/3
• Output Current (Sinking Type): 50 mA
• Connector Type: SCSI VHDCI 68 p & Phoenix Contact DFMC
• Specific Cables for Servo: itsubishi, Yaskawa, Panasonic, Delta, General Purposed

Ordering Information

• EPS-7002 - EtherCAT Slave Module - 2-CH Pulse-Train Motion Control
