Features
- Advanced NVIDIA® Jetson AGX Orin™/ Jetson AGX Orin™ Industrial platform delivers up to 275 TOPS AI performance with JetPack 6.0 supported
- The latest NVIDIA Ampere™ architecture, featuring with 2048 NVIDIA® CUDA® cores and 64 Tensor cores
- IP67 Anti-dust and Waterproof Chassis design
- 1 PCIe Gen3 x8 expansion slot supports optional multiple 10GigE/PoE LAN/USB connections (by request)
- 2 Isolated CAN-FD, 2 COM RS-232/422/485
- 6 GigE LAN with 4 PoE+, 2 USB 3.1, 1 Digital Display supports 4K60
- DC 9V to 50V wide range power input, Software Ignition Power Control
Parametry techniczne:
System | |
| System - CPU: | RAC-1100-R32 : 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU ,
RAC-1100-R64 : 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU RAC-1100-IND : 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
| System - GPU: | RAC-1100-R32 : 1792-core NVIDIA Ampere™ architecture GPU with 56 Tensor Cores ,
RAC-1100-R64 : 2048-core NVIDIA Ampere™ architecture GPU with 64 Tensor Cores RAC-1100-IND : 2048-core NVIDIA Ampere™ architecture GPU with 64 Tensor Cores |
| System - DL Accelerator: | 2x NVDLA Engines |
| System - Memory: | RAC-1100-R32 : 1 32GB LPDDR5 DRAM |
| System - OS: | Linux ,
NVIDIA JetPack SDK |
I/O Interface | |
| I/O Interface - USB: | 2 USB 3.1 (M12) |
| I/O Interface - Serial: | 2 COM RS-232/422/485 (M12 A-coded) |
| I/O Interface - LAN: | 2 GigE LAN (M12 X-coded) |
| I/O Interface - HDMI: | 1 HDMI 2.1 (M12) |
| I/O Interface - CAN Bus: | 2 Isolated CAN Bus support CAN FD (M12 A-coded) |
| I/O Interface - Flash: | 1 Micro USB OS flash port |
| I/O Interface - Button: | 1 Power Button with LED, 1 Recovery button |
Expansion | |
| Expansion - M.2: | 1 M.2 Key B Socket (3042/3052) ,
1 M.2 Key E Socket (2230) |
Graphics | |
| Graphics - Interface: | 1 Digital Display, up to 4K60 |
| Graphics - Video Encode: | HEVC: 2x 4K @60, 4x 4K @30, 8x 1080p @60, 16x 1080p @30 ,
H.264: 1x 4K @60, 3 X4k @30, 7x 1080p @60, 14x 1080p @30 |
| Graphics - Video Decode: | HEVC: Up to 1x 8K @30, 3x 4K @60, 7x 4K @30, 11x 1080p @60, 22x 1080p @30 ,
H.264: Up to 1x 4K @60, 3x 4K @30, 6x 1080p @60, 13x 1080p @30 |
Storage | |
| Storage - M.2: | 2 M.2 Key M Socket (2280) |
| Storage - eMMC: | 1 eMMC 5.1, 64GB |
ETHERNET | |
| Ethernet - LAN 1: | 10/100/1000 Base-T Ethernet GigE LAN, X-coded M12 Connector |
| Ethernet - LAN 2: | 10/100/1000 Base-T Ethernet GigE LAN, X-coded M12 Connector |
PoE+ | |
| PoE+ - LAN 3: | IEEE 802.3at (25.5W/48V) GigE PoE+ LAN, X-coded M12 Connector |
| PoE+ - LAN 4: | IEEE 802.3at (25.5W/48V) GigE PoE+ LAN, X-coded M12 Connector |
| PoE+ - LAN 5: | IEEE 802.3at (25.5W/48V) GigE PoE+ LAN, X-coded M12 Connector |
| PoE+ - LAN 6: | IEEE 802.3at (25.5W/48V) GigE PoE+ LAN, X-coded M12 Connector |
| PoE+ - : | Total PoE power budget support up to 60W at 25°C, 30W at 70°C |
Power | |
| Power - Power Input: | DC 9V to 50V |
| Power - Power Interface: | 4-pin K-Code M12 connector |
Mechaniczny | |
| Mechanical - Dimensions: | 260 mm x 330 mm x 80 mm (10.23" x 13" x 3.14") |
| Mechanical - Weight: | 7 kg (15.43 lb) |
| Mechanical - Mounting: | Wallmount |
Środowisko | |
| Environment - Operating Temperature: | 30W TDP Mode : -25°C to 70°C (-13°F to 158°F), with 0.63 m/s air flow ,
40/50W TDP Mode : -25°C to 55°C (-13°F to 131°F), with 0.63 m/s air flow |
| Environment - Storage Temperature: | -40°C to 85°C (-40°F to 185°F) |
| Environment - Humidity: | 5% to 95% Humidity, non-condensing |
| Environment - Relative Humidity: | 95% @ 70°C |
| Environment - Shock: | Operating, MIL-STD-810G, Method 516.7, Procedure I |
| Environment - Vibration: | Operating, MIL-STD-810G, Method 514.6, Procedure I, Category 4 |
| Environment - EMC: | CE, FCC, EN50155, EN50121-3-2, IP67 |
