Mini PCIe 2-port PoE+ GigE Card, IEEE 802.3at PoE+, dual 10/100/1000 BASE-T, IEEE 802.3, IEEE 802.3u, IEEE 803.3ab Compliant, Intel® I210 Gigabit LAN
Cechy
- 2 GigE LAN ports support IEEE 802.3at PoE+ with 12V to 24V Power Input
- -40°C to 85°C Operating Temperature
- 9.5KB Jumbo Frame, Link Aggregation, Teaming Functions
- IEEE 802.3, 802.3u and 802.3ab compliant
- Supports IEEE 802.3x Full Duplex Flow Control
- Supports IEEE 802.1P Layer 2 Priority Encoding
- Supports IEEE 802.1Q VLAN Tagging
- Crossover Detection, Auto Correction, and Auto Negotiation Operation
Specyfikacja
| Ethernet | |
| Interface | PCI Express x1 |
| Controller | Intel® I210 Gigabit LAN |
| Data Rate | 10/100/1000 Mbps |
| Number of Port | 2 |
| Jumbo Frame | 9.5KB supported |
| Link Aggregation (LAG) | Present |
| Connector | 8-pin RJ45 |
| PoE Standard | IEEE 802.3at compliant |
| Power Requirement | |
| Input |
12V to 24V
|
| Output | Up to 25.5W Power Output at 48V DC per port |
| Mechanical | |
| Dimensions (W x L) |
- Mini Card : 30mm x 51mm
- Daughter Card : 56mm x 61mm
- Cable Length : 300mm
|
| Weight | 145 g |
| Environment | |
| Operating Temperature | -40°C to 85°C (-40°F to 185°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% Humidity, non-condensing |
| Relative Humidity | 95% @ 85°C |
| EMC | CE, FCC |
| Packing List | |
|
1 PMX-100 PoE GigE Card
|
|
|
1 RJ45 Daughter Card
|
|
| 1 Connection Cable | |
|
1 Driver CD
|
|
|
1 Screw Kit
|
|
| 1 Bracket |
