3I525HW-AR000

Komputer jednopłytkowy 3.5" z Intel Atom D525 1.8 GHz, VGA, 2x GbE, 5x RS-232/485, 1x RS-232/422/485, 7x USB 2.0, 2x SATA i HD-audio (-20 ~ +70°C); zasilanie 6 ~ 36 Vdc

Specifications

• Chipset: Intel Pineview-D + ICH8M
• Memory:
  • Type/Capacity: DDR3 800 MT/s, Max up to 4 GB
  • SO-DIMM: 1
  • On board Memory: N/A
• SSD storage:
  • CF (CFast): CF
  • mSATA: Optional
  • On Board SSD: Optional
• VGA: Yes (Internal)
• LVDS: N/A
• Touch Screen: N/A
• DVI/HDMI: N/A
• Ethernet: 2x Realtek GbE
• Audio: Line-out / Mic-in / Line-in Internal
• Mini-PCI: 1
• Mini-PCIe:
  • Slot 1: PCIe / USB
  • Slot 2: PCIe / USB / mSATA (option)
• SIM Card Holder: 1
• SATA: 2
• USB: 7x USB 2.0 (internal)
• Serial IO: 5x RS-232 (internal) optional to RS-485,
  1x RS-422/485 (internal) optional to RS-232
• GPIO: 8x DI / 8x DO (optional)
• WDT: Yes
• PS2 KB/MS: Internal
• Power Input: Wide Range DC IN +9 ~ +36 V
• Expansion: GPS, IEEE1394, 3G/4G, Bluetooth, WI-FI, I/O
• Operating Temp.: -20 ~ +70°C
• Chassis:
  WaterProof System

Ordering Information

• 3I525HW-AR000 - 3.5" SBC with dual-core Intel Atom D525 1.8 GHz CPU and VGA, 2x GbE, 5x RS-232/485, 1x RS-232/422/485, 7x USB 2.0, 2x SATA and HD-audio interface (-20 ~ +70°C); 6 ~ 36 Vdc power
