DAQ-2208

Karta 3.3/5 V PCI - 48/96 wejść analogowych 12-bitowych 3 MS/sek i 24 wejścia-wyjścia cyfrowe

Features

• Supports a 32-bit 3.3 V or 5 V PCI bus
• 96-CH single-ended or 48-CH differential analog inputs
• Onboard 1 k-sample A/D FIFO
• Bipolar or unipolar analog input ranges
• Programmable gains of x1, x2, x4, x5, x8, x10, x20, x40, x50, x200
• 1024-configuration channel gain queue
• Scatter-gather DMA for analog inputs
• 24-CH TTL digital input/output
• Analog and digital triggering
• Fully auto calibration
• Multiple cards synchronization through SSI (System Synchronization Interface) bus

Specifications

• Analog Input


• Resolution: 12 bits, no missing codes
• Number of channels: 96 single-ended or 48 differential
• Channel gain queue size: 1024
• Maximum sampling rate: 3 MS/s
• Programmable gain: 1, 2, 4, 5, 8, 10, 20, 40, 50, 200
• Bipolar input ranges:
  ±10 V, ±5 V, ±2.5 V, ±2 V, ±1.25 V, ±1 V, ±0.5 V, ±0.25 V, ±0.2 V, ±0.05 V
• Unipolar input ranges:
  0-10 V, 0-5 V, 0-4 V, 0-2.5 V, 0-1 V, 0-0.5 V, 0-0.4 V, 0-0.1 V
• Offset error: ±1 mV
• Gain error: ±0.03 % of FSR
• Input Coupling: DC
• Overvoltage protection: Power on: Continuous ±30 V, Power off: Continuous ±15 V
• Input Impedance: 1 GΩ/100 pF
• CMRR (gain = 1): 90 dB
• Settling time: 1 μs to 0.1 % error @ Gain = 1, 2, 4, 8
• -3 dB small signal bandwidth (gain = 1): 2 MHz
• Trigger sources: Software, external digital/analog trigger, SSI bus
• Trigger modes: Pre-trigger, post-trigger, middle-trigger, delay-trigger, and repeated trigger
• FIFO buffer size: 1 k samples
• Data Transfers: Polling, scatter-gather DMA


• Digital I/O


• Number of channels: 24-CH 8255 programmable input/output
• Compatibility: 5 V/TTL
• Data transfers: Programmed I/O


• Auto Calibration


• Onboard reference: +5 V
• Temperature drift: ±2 ppm/˚C
• Stability: ±6 ppm/1000 Hrs


• General Specifications


• Dimensions: 175 mm x 107 mm (not including connectors)
• Connector: 68-pin VHDCI female x 2
• Operating temperature: 0 to 55˚C
• Storage temperature: -20 to 70˚C
• Humidity: 5 to 95 %, non-condensing
• Power requirements: +5 V 0.95 A typical

Software Support

• Operating Systems


• Windows 7/Vista/XP/2000/2003 Server
• Linux


• Recommended Software


• AD-Logger
• VB.NET/VC.NET/VB/VC++/BCB/Delphi
• DAQBench


• Driver Support


• DAQPilot for Windows
• DAQPilot for LabVIEW
• DAQ-MTLB for MATLAB
• D2K-DASK for Windows
• D2K-DASK/X for Linux

Ordering Information

• DAQ-2208 - 48/96 x 12-bits 3 MS/s Ultra High-Density Analog Input Card

Accessories

• Terminal Boards


• DIN-68S-01 - Terminal Board with One 68-pin SCSI-II Connector and DIN-Rail Mounting (cables are not included)


• Cables


• ACL-10568-1 - 68-Pin SCSI-VHDCI cable


• SSI Bus Cables (for multiple cards synchronization)


• ACL-SSI-2 - SSI Bus cable for 2 devices


• ACL-SSI-3 - SSI Bus cable for 3 devices


• ACL-SSI-4 - SSI Bus cable for 4 devices
