Produkcja karty PCI-7348 została zakończona. Przykładowy zamiennik: AFL3-W07A-BT-N1-PC-2G Podobne produkty można znaleźć w kategorii nadrzędnej. Jeśl potrzebujesz pomocy w wyborze zamiennika - skontaktuj się z nami bezpośrednio.
Features
- 8” LED backlight LCD panel with resistive type touch screen
- Built-in 2 M pixel camera with low light capability
- Built-in digital microphone
- Selectable AT/ATX power mode via internal switch
- Fanless cooling system
- System memory up to 2 GB SDRAM
- Built-in 802.11b/g/n Wireless LAN
- Built-in two 1.5 W speakers
- One CompactFlash slot
- IP64 compliant front panel
- IEI One Key Recovery solution allows you to create rapid OS backup and recovery
(Suggest over 4 GB storage capacity)
Specifications
- LCD Size: 8"
- Max Resolution: 800 x 600
- Brightness (cd/m2): 250
- Contrast Ratio: 400 : 1
- LCD Color: 262 K
- Pixel Pitch (mm): 0.2025 (H) x 0.2025 (V)
- Viewing Angle (H-V): 140º / 130º
- Backlight MTBF: 30000 hrs (LED backlight)
- SBC Model: AFLMB-945GSE-N270-R10
- CPU: Intel Atom Processor N270 (512 K L2 Cache, 1.60 GHz, 533 MHz FSB)
- Chipset: Intel 945GSE + ICH7M
- RAM: Supports one 400 MHz or 533 MHz DDR2 SO-DIMM (2 GB max.)
- I/O Ports:
1 x RS-232 COM Port
1 x RS-232/422/485 COM Port
2 x RJ-45 for GbE
2 x USB 2.0
1 x Power Switch
1 x Reset Button
1 x External SATA
1 x Audio Port
1 x Power Jack - SSD: CF Type II
- Watchdog Timer: Software programmable supports 1 ~ 255 sec. system reset
- Audio: AMP 1.5 W + 1.5 W (internal speakers)
- Camera Module: 2 M pixel camera with digital microphone
- Wireless Connection:
1 x Wireless LAN 802.11 b/g/n Module (internal PCIe Mini card interface) - Construction Front Panel: ABS + PC Plastic front frame
- LED Function: 1 x Power on/off LED on front panel
- Mounting: Panel, Wall, Rack, Stand and Arm VESA 75 x 75 mm
- Front Panel Color: Gray 7539U
- Dimensions (WxHxD): 234 x 177 x 43 mm
- Operation Temperature: -10 ~ +50°C
- Storage Temperature: -20 ~ +60°C
- N/G Weight: 0.8 Kg
- IP Level: IP64 compliant front panel
- Safety & EMC: CE / FCC / CB / CCC
- Touch Screen: 5-wire resistive type (touch controller IC is on board)
- Power Adapter:
P/N: 63000-FSP036RAB608-RS
36 W Power Adapter
Input: 90 ~ 264 Vac, 50/60 Hz
Output: 12 Vdc - Power Requirement: 12 Vdc
- Power Consumption: 25 W
Ordering Information
- AFL-08B-N270/R/1G-R23 - 8" 250 cd/m², SVGA fanless panel PC with Intel Atom N270 1.6 GHz, 802.11b/g/n wireless module, touch screen, 2 M pixel camera with digital microphone, 1 GB DDR2 533 MHz, R22
Optional Accessories
- AFLPK-12 - Panel Mounting Kit
- AFLWK-12 - Wall Mounting Kit
- AFLRK-08 - Rack Mounting Kit
- ARM-11-RS - Arm
- ARM-31-RS - Arm
- STAND-100-RS - Stand
- VSTAND-A10-R11 - Vstand
- IDD-930160-KIT - 9 ~ 30 Vdc to 12 Vdc converter module
- AFLP-08BMSI-U - Hybrid Card Reader
- AFLP-08BMSR-U - Magnetic Stripe Reader
- AUPS-A10-R10 - DC 12 V Input UPS (7.4 V 3800 mAH)
- AUPS-A20-R10 - DC 9 ~ 36 V Input UPS (7.4 V 3800 mAH)
- AFL-BT-KIT02-R10 - Bluetooth V2.0+EDR
Optional Operating Systems
- AFLCF-08-N270-CE060-R23 - OS Win CE 6.0 (128 MB CF card)
Note: Win CE application without digital microphone function
- AFLCF-08-N270-XPE-R23 - OS Win XPE (1 GB CF card)
- AFLCF-08-N270-LNX-R23 - OS Linux (2 GB CF card)
- AFLCF-08-N270-WES7E-R23 - OS Win 7 Embedded (4 GB CF card)
Parametry techniczne:
| End of Life: | Tak |
