IMB-T10

Features

• Intel AtomD2550 Processor + Intel NM10 Express Chipset
• VGA, HDMI, LVDS display output
• PCI, PCIe x1 for flying Cable/riser card, and Mini PCIe full card slot
• 10 x COM ports

Specifications

• Processor & System


• CPU: Intel AtomD2550, 1.86 GHz, 1M Cache, 32 nm, 10 W TDP, FCBGA
• Chipset: Intel NM10 Express Chipset
• Memory: 1 x 204-pin SO-DIMM socket
  DDR3 800/1066 MHz, up to 4 GB
• BIOS: AMI 16Mb SPI BIOS
• Watchdog Timer: 1-255 sec or 1-255 min software programmable, can generate system reset
• Smart Fan Control: Yes
• Hardware Monitor: CPU/System temperature, and onboard DC voltages
• Operation Systems:
  • Windows 7 32bit,
  • Fedora 19


• I/O Interfaces


• Serial ATA: 2 x Serial ATA II ports with 3.0 Gb/s data transfer rate
  (One SATAII Interface shares with mSATA IF)
• Expansion Slots:
  • 1 x PCI,
  • 1 x PCIe x1(for flying cable/riser card),
  • 1 x Mini PCIe full card slot (PCIe 1.0a/USB2.0/mSATA IF support)
• USB: 7 x USB 2.0 ports (4 x rear side, 3 x onboard pin headers),
  additional one USB2.0 onboard pin headers is available if
  1 x Mini PCIe full card slot USB 2.0 IF is not occupied
• KB/MS: 1 x on board pin headers for PS/2 keyboard/mouse
• Serial Port:
  • 9 x RS-232(8x on board pin headers),
  • 1 x RS-232/422/485
• Digital IO: 14 x digital IO (7 in/7 out) plus one +5 V pin and one GND pin


• Audio


• Audio Codec: Realtek ALC887
• Rear Panel Output: Line-out, Mic-in
• Front Panel Output: Line-out, Mic-in (on board pin headers)


• Display


• Graphics: Intel Graphics Media Accelerator 3650
• VGA: Resolution up to 1920*1200 @60Hz
• LVDS:
  • 1 x Single channel 24bit LVDS resolution up to 1440*900@60 Hz
  • 1 x Dual channel 24bit LVDS resolution up to 1920*1080@60 Hz
• HDMI: HDMI 1.3a support. Resolution up to 1920x1200 @60 Hz
• Dual Display: VGA+LVDS, VGA+HDMI, LVDS+HDMI


• Communication


• Ethernet Controller: 2 x 10/100/1000BASE-T Gigabit Ethernet ports by Realtek RTL8111E
• Wake On LAN: Yes
• Ethernet Interface: PCIe x1 Bus
• SIM Card Slot: 1 x on board mini-SIM Card slot


• Mechanical and Environmental


• Form Factor: Mini-ITX
• Power Input: 12 Vdc IN screw type connector or 12 Vdc IN ATX 4pin connector.
  Both power input connectors can not be plug-in simultaneously
• Dimensions (L x W): 170 x 170 mm
• Operating Temp.: 0 ~ +60˚C
• Storage Temp.: -20 ~ +80˚C
• Certifications: CE, FCC Class A
• Relative Humidity: 10 ~ 90%, non-condensed

Ordering Information

• IMB-T10 - Mini-ITX Embedded Motherboard with Intel Atom D2550 processor with heatsink

Optional Accessories

• SATA Data and power cable


• 2-port PS/2 Cable with bracket


• 2-port USB 2.0 Cable with bracket


• 4-port COM Cable
