Features
- Dual 3U CompactPCI systems, each with five peripheral slots and one system slot
- 1/1 250 W CompactPCI Power supplies
- Temperature, voltage, and fan monitoring LEDs
- Supports current sharing on +5 V, +3.3 V, and +12 V
- PICMG 2.11 47-pin power interface
- Hot-swappable cooling fans & filter
- Supports rear I/O backplane with P2 connectors for cPCI 80 mm depth RTMs
- CompactPCI Standards: CompactPCI 2.0 R2.0
- Form Factor: 3U CompactPCI 80 mm depth rear I/O
- Enclosure:
• EIA RS-310C 19" 4U high rackmount enclosure
• Coated metal plate outer covering
• Guarded power switch and reset button - Alarm Module:
• Monitors inner chassis temperature and fan status
• Abnormal status will generate alarm and LED warning
• Alarm reset
• LED shows power voltage status on 5 V, 3.3 V, 12 V, and -12 V - Cooling System:
• Front-access hot-swappable low noise fan trays for intake:
• 12 Vdc brush-less, ball bearings
• Five fan trays with 36 CFM/fan
• Rated fan speed 2800 RPM
• Rated power for each fan: 1.56 W - Power Supply: dual 250 W CompactPCI Power Supply
- Backplane: dual 6-slot system (1 x System Slot + 5 x Peripheral Slot)
- Dimensions (W x H x D): 448.4 x 177.8 x 288 mm, excluding brackets
- Operating Temp.: 0 ~ +60˚C
- Storage Temp.: -20 ~ +80˚C
- Humidity: 5% to 95%, non-condensing
- Shock: 15 G peak-to-peak, 11 ms duration, non-operation
- Vibration:
• Non-operation: 1.8 Grms, 5 ~ 500 Hz, each axis
• Operation: 0.5 Grms, 5 ~ 500 Hz, each axis, tested with 2.5" HDD
- cPCIS-2842 - 3U CompactPCI Subsystem with dual 6-slot Backplane, dual 1-slot 80 mm RTM (system slot) and dual 250 W CompactPCI Power Supply
