MXE-5301 (End of Life)

Bezwentylatorowy komputer do zabudowy z procesorem quad-core Intel Core i7-2110QE 2.1 GHz, 4 GB DDR3 RAM, VGA/DVI-I, 4x GbE, 2x RS-232, 2x RS-232/422/485, 2x USB 3.0, 4x USB 2.0, 1x SATA-3 i audio (0 ~ +50°C); zasilanie 9 ~ 32 Vdc

---

Features

• Intel Core i7-2710QE (Quad-Core) Processor + Intel QM67 chipset
• Rugged, up to -20 ~ +60°C fanless operation (w/ industrial SSD)
• Intel Active Management Technology 7.0 support
• Optional wireless function enhancement (WCDMA, 802.11 a/b/g/n, BT3.0, AGPS)
• 1x on-board SATA-3 (6.0 Gb/s) port
• 6x USB ports (2x USB 3.0 port + 4x USB 2.0 port), 4x DI + 4x DO w/ 1.5KV isolation, 4x GbE ports
• 1x external CFast socket; 2x onboard mini PCIe card sockets
• 2x BIOS programmable RS-232/422/485 (COM1&2), 2x RS-232 (COM3&4)

Specifications

• System Core


• Processor: Intel Core i7-2710QE 2.1 GHz processor
• Chipset: Intel Mobile Platform Controller Hub (QM67)
• Video:
  • VGA+DVI dual display output by DVI-I connector
  • Analog CRT, supports QXGA (2048 x 1536) resolution
  • DVI output, supports up to 1920 x 1080 resolution
• Memory: 4 GB DDR3 1066 MHz SODIMM module
  (Max. capacity 16 GB with 2 SO DIMM socket option)


• I/O Interfaces


• Ethernet: 4x GbE ports (2x Realtek 8111C + 1x Intel 82574IT + 1x 82579LM PHY)
• Serial Ports: 2x BIOS programmable RS-232/422/485 (COM1 & COM2),
  2x RS-232 (COM3 & COM4)
• USB: 4x USB 2.0 ports & 2x USB 3.0 ports
• DIO: 4x DIO w/ 1.5 kV isolation
• Audio: 1x mic-in and 1x Line-out
• KB/MS: 1x PS/2 keyboard and 1x PS/2 mouse (combo)
• Mini PCIe: 2x internal PCIe mini card sockets
• USIM: 1x USIM socket for 3G communication (used for a 3G-mini module)
• WDT: Hierarchical WDT supported


• Power Supply


• DC Input: Built-in 9 ~ 32 Vdc wide-range DC input
  3P pluggable connectors with latch (GND, V-, V+)
• AC Input: Optional 160 W AC-DC adapterfor AC input


• Storage Device


• SATA HDD: 1x SATA-3 port for 2.5" HDD/SSD installation
• CompactFlash: 1x CFast slot
• eSATA: 1x eSATA interface connectors on rear panel for storage expansion


• Mechanical


• Dimensions (W x D x H): 230 x 205 x 75 mm
• Weight: 3.8 kg
• Mounting: Wall-mount kit


• Environmental


• Operating Temperature:
  • Standard: 0 ~ +50°C
  • Extended temperature option: -20 ~ +60°C (w/industrial SSD or CFast)
• Storage Temperature: -40 ~ +85°C
• Humidity: ~95% @ 40°C (non-condensing)
• Operating Vibration:
  • 5 Grms, 5 ~ 500 Hz, 3 axes (w/ CFast or SSD)
  • 0.5 Grms, 5 ~ 500 Hz, 3 axes (w/ 2.5" HDD)
• Operating Shock:
  50 G, half sine 11 ms duration (w/ CFast or SSD)
• ESD: Contact +/- 4 kV, Air +/- 8 kV
• EMC: CE and FCC Class A

Software Support

• OS Information


• Windows: XP / XP Embedded / 7
• Linux: Linux Distribution by Request

Ordering Information

• MXE-5301 - Fanless embedded system with quad-core Intel Core i7-2110QE 2.1 GHz CPU, 4 GB DDR3 RAM and VGA/DVI-I, 4x GbE, 2x RS-232, 2x RS-232/422/485, 2x USB 3.0, 4x USB 2.0, 1x SATA-3 and audio interface (-0 ~ +50°C); 9 ~ 32 Vdc power

Optional Accessories

• 8 GB DDR3 Upgrade - Upgrade to 8 GB DDR3 memory


• 16 GB DDR3 Upgrade - Upgrade to 16 GB DDR3 memory


• 500 GB HDD Option - Factory-installed 500 GB SATA hard disk drive (0 ~ +50°C)


• 2 TB HDD Option - Factory-installed 2 TB SATA hard disk drive (0 ~ +50°C)


• 8 GB SSD Option - Factory-installed of 8 GB SLC type industrial-grade SATA solid state disk (-40 ~ +85°C)


• 32 GB SSD Option - Factory-installed of 32 GB SLC type industrial-grade SATA solid state disk (-40 ~ +85°C)


• 64 GB SSD Option - Factory-installed of 64 GB MLC type industrial-grade SATA solid state disk (-40 ~ +85°C)


• 160 W AC-DC Adapter - 160 W industrial-grade AC-DC adapter (-20 ~ +70°C)



• Wireless Module Option - 3G/WiFi/BT/GPS wireless modules (3G/GPS for MXE-5301/5302/5303 only)


• Extended Temperature Option - Optional screening to extend the operating temperature
  of the MXE-5301 to -20 ~ +60°C and MXE-5302/5303 to -20 ~ +70°C
