Features
- PXA270, 520 MHz CPU
- Linux kernel 2.6.19 Inside
- Embedded Service: Web Server, FTP Server,
- Telnet Server, SSH Server
- 64 MB Flash, 128 MB SDRAM
- Built-in Ethernet, USB, RS-232, RS-485 Ports
- Built-in 800 × 600 VGA Port
- I/O Expansion Board Optional
- Operating Temperature: -25 ~ +75°C
- System Software
- OS Linux kernel: 2.6.19
- Embedded Service: Web Server, FTP Server, Telnet Server, SSH Server
- SDK Provided: Standard LinPAC SDK for Windows and Linux by GNU C language
- CPU Module
- CPU: PXA270, 520 MHz
- SDRAM: 128 MB
- NVRAM: 31 Byte (Battery backup, data valid up to 10 years)
- Flash: 64 MB
- EEPROM: 16 KB
- Expansion Flash Memory: microSD socket with one 2 GB microSD card
(support up to 32 GB microSDHC card) - RTC (Real Time Clock): Provide second, minute, hour, date, day of week, month, year
- 64-bit Hardware Serial Number: Yes, for Software Copy Protection
- Dual Watchdog Timers: Yes
- LED Indicator: 3 Dual-Color LEDs (PWR, RUN, L1 ~ L4; RUN, L1 ~ L4 for user programmable)
- Rotary Switch: Yes (0 ~ 9)
- VGA & Communication Ports
- VGA: Yes, 640 × 480 / 800 × 600
- Ethernet: RJ-45 x 1, 10/100 Base-TX
(Auto-negotiating, Auto MDI/MDI-X, LED indicators) - USB 1.1 (host): 2
- Audio (Microphone-In and Earphone-Out): -
- COM 1: RS-232 (RxD, TxD and GND); Non-isolated
- COM 2: RS-485 (Data+, Data-); 2500 Vdc isolated
- COM 3: RS-232 (RxD, TxD and GND); Non-isolated
- I/O Expansion
- I/O Expansion Bus: I/O expansion board optional
- Mechanical
- Dimensions (W x L x H): 91x 132 x 52 mm
- Installation DIN-Rail
- Environmental
- Operating Temperature: -25 ~ +75°C
- Storage Temperature: -30 ~ +80°C
- Ambient Relative Humidity: 10 ~ 90% RH (non-condensing)
- Power
- Input Range: +10 ~ +30 Vdc
- Isolation: 1 kV
- Consumption: 4.8 W
- LP-5131-EN CR – PAC with Linux kernel 2.6.19 and one LAN port (English Version of OS) (RoHS)
