Features
- Built-in VGA Port
- I/O Module Hot Swap Ability (For High Profile I-87K Modules Only)
- Rich I/O Expansion Ability (RS-232/485, Ethernet, FRnet, CAN)
- Built-In 63 MB Flash Disk
- Dual Watchdog Timer
- Dual Battery-Backup SRAM (512KB)
- Dual Ethernet Ports
- Redundant Power Input
- Ventilated Housing Design Allows Operation Between -25℃ ~ +75℃
- Windows CE.Net 5.0
- Remote Maintenance via FTP Server and VCEP Software
- Built-In OPC Server (NAPOPC_CE5)
- Rich Software Solutions (VS.Net 2003/2005/2008 and eVC)
- Upgrading applications from WinCon to WinPAC Just Copy and Play
- System Software
- OS: Windows CE 5.0
- .Net Compact Framework: 2.0
- Embedded Service: FTP server, Web server (supports VB script, JAVA script), Embedded SQL server
- SDK Provided: DLL for eVC, DLL for Visual Studio.Net 2003/2005/2008
- CPU Module
- CPU: PXA270 or compatible (32-bit and 520 MHz)
- SDRAM: 128 MB
- Dual Battery Backup SRAM: 512 Kbytes (for 5 years data retain)
- Flash: 128 MB (64 MB for OS image, 63 MB for built-in Flash disk, 1 MB for registry)
- EEPROM: 16 Kbytes; Data Retention: 40 years; 1,000,000 erase/write cycles
- microSD: with one 2 GB microSD card (can support 16 GB microSD card)
- RTC (real time clock): Year-2000 compliance; seconds, minutes, hours, date of the month; month, year, valid up from 1980 to 2079
- 64-bit Hardware Serial Number: Yes
- Dual Watchdog Timer: Yes
- Programmable LED Indicator: 1
- Rotary Switch: Yes (0 ~ 9)
- DIP Switch: Yes (8 bits)
- VGA & Communication Ports
- VGA: resolution: 1024 x 768, 800 x 600, 640 x 480; with one extra GPU.
- Ethernet: RJ-45 x 2, 10/100 Base-TX (Auto-negotiating, LED indicators)
- USB 1.1 (host): 2 ports
- COM 0: Internal communication with I-87K modules in slots
- COM 1: RS-232 (to update firmware) (RXD, TXD and GND); Non-isolation
- COM 2: RS-485 (D2+, D2-); self-tuner ASIC inside; Isolation: 3000 Vdc
- COM 3: RS-232/RS-485 (RXD, TXD, CTS, RTS and GND for RS-232, Data+ and Data- for RS-485); Non-isolation
- COM 4: RS-232 (RXD, TXD, CTS, RTS, DSR, DTR, CD, RI and GND); Non-isolation
- I/O Expansion Slots
- Slot Number: 4 slots (for High Profile I-8K and I-87K modules only)
- Hot Plug: for High Profile I-87K modules only
- Mechanical
- Dimensions (W x L x H): 231 mm x 132 mm x 111 mm
- Installation: DIN-Rail or Wall Mounting
- Environmental
- Operating Temperature: -25 ~ +75 °C
- Storage Temperature: -30 ~ +80 °C
- Ambient Relative Humidity: 10% ~ 90% RH, non-condensing
- Power
- Input Range: +10 ~ +30 Vdc
- Isolation: 1 kV
- Redundant Power Inputs: Yes, with one power relay (1 A @ 24 Vdc) for alarm
- Capacity:
1.1 A, 5 V supply to CPU and backplane,
4.9 A, 5 V supply to I/O expansion slots, total 30 W
- Consumption: 9.1 W (0.38 A @ 24 Vdc)
- WP-8431-EN-G – Standard WinPAC-8000 with 4 I/O slots (English version of OS)
Parametry techniczne:
Seria: | WP-8000 |
