Karta procesorowa PICMG 1.0 - WSB-H810

Karta PICMG 1.0 SBC z podstawką LGA1150 dla procesorów Intel Core i7/i5/i3/Pentium, VGA/iDP, 2 x GbE, 4 x RS-232, 1 x RS-422/485, 2x USB 3.0, 7 x USB 2.0, 2 x SATA-3, 1x SATA-2 i HD-audio (-20 ~ +60°C)

Features

• Full-size PICMG 1.0 with LGA1150 Intel CPU
• Two 1600/1333 MHz DDR3 SDRAM DIMM slots support up to 16 GB of memory
• Dual Intel Gigabit Ethernet LAN controller
• SATA 6Gb/s and USB 3.0 supported
• IEI One Key Recovery solution for rapid OS backup and recovery
• TPM v1.2 hardware security function supported by TPM module
• Stiffener bars
• IEI jumper-less function

Specifications

• CPU: 4th generation LGA1150 Intel Core i7/i5/i3, Pentium or Celeron processor supported
• Chipset: Intel H81
• Memory: Twp 240-pin 1600/1333MHz dual-channel DDR3 & DDR3L SDRAM unbuffered DIMMs
  support up to 16GB
• BIOS: UEFI
• Graphics:
  Intel HD Graphics Gen 7.5 supports DX11.1 and OpenCL 1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode
• Display Output:
  Dual independent display
  VGA (up to 1920x1200 @ 60 Hz)
  iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160 @60 Hz)
• Ethernet:
  LAN1: Intel I217-LM Ethernet Controller
  LAN2: Intel I211-AT Ethernet Controller
• Audio: 7.1 channel HD Audio supported by IEI AC-KIT-892HD kit
• External I/O Interface:
  2x RJ-45
  2x USB 2.0
  1x VGA
• Internal I/O Interface:
  1x IR (1x5 pin)
  1x KB/MS (1x6 pin)
  1x LPT(2x13 pin)
  1x RS-422/485 (1x4 pin, P=2.0)
  4x RS-232 (2x5 pin, P=2.54)
  1x USB 2.0 (180 degree type A)
  4x USB 2.0 (2x4 pin, P=2.54)
  2x USB 3.0 (2x10 pin)
  2x SATA 6Gb/s, 1x SATA 3Gb/s (Intel H81 supports AHCI, no RAID)
• Front Panel:
  1 x Front panel (2x7 pin, Power LED, HDD LED, Speaker, Power Button, Reset Button)
• LAN LED: 2 x LAN LED (1x2 pin)
• Digital I/O: 1 x 8-bit digital I/O (2x5 pin)
• TPM: 1 x TPM (2x10 pin)
• SMBus: 1 x SMBus (1x4 pin)
• I²C: 1 x I²C (1x4 pin)
• Expansion:
  1 x mSATA (SATA 3Gb/s)
  1 x PCIe Mini slot
  PCI and ISA signal via golden finger
• Watchdog Timer: Software programmable supports 1~255 sec. system reset
• Fan Connector:
  1 x CPU smart fan (1x4 pin)
  1 x System smart fan (1x3 pin)
• Power Supply: 5 V/12 V, AT/ATX support
• Power Consumption: 5 V@3.4 A, 12 V@0.36 A, Vcore_12 V@7.48 A, 3.3 V@1.42 A, 5 Vsb@0.13 A
  (Intel Core i7-4770K 3.90 GHz CPU with 8 GB (two 4 GB) 1333 MHz DDR3 memory)
• Operating Temperature: -20 ~ +60°C
• Storage Temperature: -30 ~ +70°C
• Operating Humidity: 10 ~ 95%, non-condensing
• Dimensions: 338 x 122 mm
• Weight: GW: 1000 g / NW: 260 g

Ordering Information

• WSB-H810-R10 - Full-size PICMG 1.0 CPU card supports LGA1150 Intel Core
  i7/i5/i3, Pentium and Celeron CPU per Intel H81, DDR3, VGA/iDP, Dual Intel GbE,
  USB 3.0, SATA 6Gb/s, PCIe Mini, mSATA, RS-232, HD Audio and RoHS

Optional Accessories

• 19800-000051-RS - Dual RS-232 cable, 230 mm, P=2.54

• 19800-000075-RS - PS/2 KB/MS Y-cable with bracket, 220 mm

• 19800-003100-100-RS - USB 2.0 cable, 300 mm, P=2.54

• 19800-010500-200-RS - USB 3.0 cable with bracket, 457 mm

• 32102-000100-200-RS - SATA power cable, MOLEX 5264-4P to SATA15P

• 32200-015100-RS - LPT flat cable, 280 mm

• 32200-074800-RS - RS-422/485 cable, 200 mm, P=2.0

• AC-KIT-892HD-R10 - 7.1 channel HD Audio kit with Realtek ALC892 supports dual audio streams

• CF-1150SB-R11 - Special cooler kit for LGA1150, high-performance compatible, 65 W

• CF-1150SC-R20 - Special cooler kit for LGA1150, 1U chassis compatible, 65 W

• CF-1150SE-R10 - Special cooler kit for LGA1150, high-performance compatible, 95 W

• CF-1150SF-R10 - Special cooler kit for LGA1150, high-performance compatible, 54 W

• DP-DP-R10 - DisplayPort to DisplayPort converter board (for IEI iDP connector)

• DP-DVI-R10 - DisplayPort to DVI-D converter board (for IEI iDP connector)

• DP-HDMI-R10 - DisplayPort to HDMI converter board (for IEI iDP connector)

• DP-LVDS-R10 - DisplayPort to LVDS converter board (for IEI iDP connector)

• DP-VGA-R10 - DisplayPort to VGA converter board (for IEI iDP connector)

• TPM-IN01-R11 - 20-pin Infineon TPM module, software management tool, firmware V3.17
